MID-SECTION - 5A-990-826148R2 MARCH 1997
Drive Shaft Housing Components
TORQUE
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 2 SCREW (M8 x 1.25 x 55) 198 16.5 22.4
2 1 GROMMET-Water Tube
3 1 CLAMP-Water Tube
4 1 SEAL-Water Tube
1 WATER TUBE (SHORT)
1 WATER TUBE (LONG)
6 1 EXHAUST TUBE
7 3 SCREW (M8 x 1.25 x 45) 198 16.5 22.4
8 1 GASKET-Drive Shaft Housing
1 ADAPTOR PLATE (BLACK)
1 ADAPTOR PLATE (GRAY)
10 4 DOWEL PIN
11 1 SCREW (M10 x .75) 198 16.5 22.4
12 1 SEAL-Bottom Cowl
13 1 COUPLER
14 1 GROMMET-Shift Shaft
15 1 SHIFT SHAFT (UPPER)
16 1 WASHER
17 1 PIN-Shift Link
18 1 COTTER PIN
19 2 SCREW (M12 x 1.75 x 162)
20 1 MOUNT
21 4 SCREW (M8 x 1.25 x 45)
22 2 WASHER
23 2 WASHER
24 2 NUT (M12 x 1.75) 50 67.8
1 TRIM COVER (BLACK)
1 TRIM COVER (GRAY)
26 1 BUMPER
27 1 SCREW (M5 x .8 x 60)
28 1 WASHER
29 1 NUT (M5 x .8)
