Connecting Cables
1-11
1
Before Use
3
4
6
Connecting the power cable
After connecting the interface cable, you must connect the power
cable.
Connect the power cable with the plug outlet of the following power
specifications.
• Voltage AC100 to 240V ± 10%
• Frequency 50/60Hz ± 1%
• Capacity 100W or more (Equivalent of 2A)
• Regarding the use of two polar plug outlet, you must connect the
auxiliary ground adapter to the plug of power cable.
Earth the green wire (ground wire) of the ground adapter. If you cannot,
consult with an electrician.
• Be sure to connect the ground wire. Using without the ground wire
causes the damage of this device and electric shock that may be very
dangerous.
To Next Page
