3-20
Setting the AUTO CUT
Performs the setting to cut off the sheet automatically after cutting is completed.
When the automatic cutting is set to “ON”, you must set the cutting pressure and the cutting speed.
1
Press the key in LOCAL mode.
2
Press to select [SET UP].
3
Press the key.
4
Press to select [AUTO. CUT].
5
Press the key.
6
Press to select ON.
• When you do not want to set AUTO CUT, select "OFF" and
proceed to Step 13.
7
Press the key.
Set Item Set Value Overview
CUT PRESS + 0 to 400 g
Set the pressure for cutting off the sheet.
Here, set the extra pressure added to the normal cutting pressure.
SLANT CUT 5, 10, 15 mm
To reduce the paper jam due to it being got hung up on the gap of the cut line
when the cut sheet is fed, set the amount of skewed cut edge.
CUT SPEED 5 to 60 cm/s
Set the speed to cut off the sheet.
• When the pinch roller 1 and 4 are set to the max. width, the automatic cutting area is as below:
About 80mm to right from inside of the pinch roller 1
About 40mm to left from inside of the pinch roller 4
• The set value is retained even when the power is turned "OFF".
• By setting extra pressure added to the normal cutting
pressure, even if you select any tool with different cutting
pressure, you can perform stable cutting off in the same
condition.
To Next Page
