3-21
3
Convenient use
6
Setting function
8
Press to set the extra pressure added to
the normal cutting pressure.
• Setting value : 0 to 400g
9
Press the key.
10
Press to set the sheet feeding amount of
slant cut.
• Setting value : 5, 10, 15 mm
11
Press the key.
12
Press to set the cutting speed.
• Setting value : 5 to 60 cm/s
13
Press the key.
14
Press the key several times to end the setting.
Setting the ROTATION
Set the origin position and the coordinate axis direction depending
on your application software.
1
Press the key in LOCAL mode.
2
Press to select [SET UP].
3
Press the key.
Set Value Overview
ON
Rotates the coordinate axis and moves the origin at
the same time.
OFF
Does not rotate.
To Next Page
