3-40
Setting the Tool Change
The carriage of this device has both tolls of a cutter for cutting and a pen for plotting. Depending on your use,
perform cutting (plotting) by switching a cutter to a pen.
Here, perform setting related to the switching operation of the cutter and the pen.
1
Press the key in LOCAL mode.
2
Press to select [SET UP].
3
Press the key.
4
Press to select "Tool Change".
5
Press the key.
• The setting of switching check is displayed.
6
Press to select ON/OFF.
7
Press the key.
• The setting of retry is displayed.
8
Press to select ON/OFF.
9
Press the key.
• The setting of switching speed is displayed.
Set Item Set Value Overview
CHECK ON/OFF
After switching tolls, check that the switching was performed properly by
moving tool downward.
RETRY ON/OFF
When this is “ON”, if the switching was judged as NG in the switching check,
perform switching operation again.
SPEED 1 to 30 cm/s
Set the moving speed of the carriage from 1cm front of the tool switching
position to the switching position.
• When you switch the tool to pen, by moving tool downward,
the pen tip touches the pen line and ink blot the pen line.
When you do not wish ink to blot the pen line, set this to
“OFF”.
