Special Imaging Modes
11-5
Functions of the parameters are described in the following table.
Parameter Description
Display Format To set the image display format in 3D image view status:
Single/Dual/Quad
Tool To set the edit type in image edit mode:
z Inside Contour
z Outside Contour
z Inside Rect
z Outside Rect
z Big Eraser
z Small Eraser
z Inside Polygon
z Outside Polygon
Edit Depth To set the edit depth in image edit mode: 0%-100%
MPR Line To set the display manner of MPR Line in image rendering mode:
Entire/Partial/Off
Probe Preset the probe model
Sub Preset
(Parameter
Package Preset)
There are five presettable parameter packages for each mode, which
are independent from each other. Every package contains a set of 3D
image rendering parameters, and can adopt parameter preset.
User Default, User Define1-User Define4
Click
; or check the box before “User Define1”-“User
Define 4”; and click the package button again to preset for the package.
Smart3D When finished parameter package setting, you can select a default
parameter package for Smart 3D.
11.1.2.3 Set menu and soft menu items
To set displayed menu and soft menu items in Image Capture, Edit, 3D Review and Reset ROI,
refer to section 17.8 for details.
11.1.3 Enter/ Exit Smart3D
Entering
z Press the [Menu] key in any exam mode, select [Other] Æ [Smart3D] in the
displayed menu to enter 3D collecting mode.
z Press the user-defined entering key for Smart 3D to enter 3D image capture
preparation status.
z Click [Smart 3D] in the soft menu in B mode.
NOTE: The system actives B mode imaging whenever you enter the 3D acquisition.
