13-1
13 Measurements
WARNING:
1. Be sure to measure areas of interest from the most
optimal image plane to avoid misdiagnosis from
inaccurate measurement values.
2. To obtain accurate Doppler flow measurement values,
make sure the transmitting beam is not perpendicular to
the flow, otherwise false readings and potential
misdiagnosis may result.
CAUTION:
1. If an image is unfrozen or the mode is changed during a
measurement, the calipers and measurement data will be
cleared from the screen. The general measurement data
will be lost (the application measurement data are stored
in the report).
2. If the system is turned off or <End Exam> is pressed
during a measurement without entering patient ID, the
data not saved will be lost.
13.1 Basic Operations
13.1.1 Entering Measurement Status
To enter the measurement status, press [Caliper] key or [Measure] key.
z Press [Caliper] key to enter general measurement status;
z Press [Measure] key to enter application measurement status.
To exit the measurement status:
z Press [Caliper] key or [Measure] key again.
You can perform measurements on a:
z zoomed image
z cine review image
z real-time image
z frozen image
13.1.2 Measurement Result and Help Information
The system displays and updates measurement results in the result display area.
The Help information concerning measurement and calculation is displayed in the Help
bar at the bottom of the screen.
