5-1
5 Set-up & Connections
5.1 System Set-up
Please read and understand the safety precautions before placing the system.
1 Turn off the power and disconnect the system from all peripherals.
2 Carry the system by holding the handle.
3 Place the system in a desired location.
4 Leave at least 20cm at the back and both sides of the system.
CAUTION:
Maintain a generous – free air flowing space around the back
and both sides of the system; failure may result due to
increased rise in system operating temperature.
5.2 Power Supply
This system can work normally only when it is connected to the external power supply or
the battery capacity is sufficient.
5.2.1 Connecting the External Power Supply
1 Connect the connector of the power adapter to the adapter port in the system.
2 Use a three-wire cable to connect the adapter with the external power supply.
3
The external power supply system must meet the following requirements:
z 100 – 240V～
z 50／60Hz
z 1.5 – 0.6A
4
The model of the power adapter:
ADP1210-01.
If you have any question about the power adapter, please contact your sales representative.
NOTE:
1. You must use the specified power adapter.
2. Do not use this power adapter in the conditions other than those specified.
5.2.2 Powered by Batteries
z When connected to the external power supply, the system is powered by the external
power. The lithium ion batteries inside it are in the charging status.
