15-1
15 Body Marks (Pictograms)
The Body Mark (Pictogram) feature is used for indicating the exam position of the patient and
transducer position and orientation.
15.1 Entering / Exiting Body Mark Mode
To enter the Body Mark status:
Press
to enter the body mark selection status.
To exit the Body Mark status:
1. Press [Body Mark] again to exit the body mark status;
2. Press the [Esc] key to confirm the current operation and exit the body mark status.
15.2 Categories of Body Marks
The Body Marks are grouped into Abdomen, Cardiac, GYN (Gynecology), OB (Obstetrics),
Urology, Small Part, Vascular, Nerve and Emergency. Each category consists of multiple
pictograms that can be selected or preset according to your workflow requirements.
15.3 Soft Menu for Body Marks
The body mark soft menu displays the setups in the current mode:
z Click [Library] to select [Abdomen], [Cardiac], [GYN], [OB], [Urology] [Small Part] or
[Vascular] and show the corresponding body marks.
z Select Display On or Off to turn On or Off the Body Mark feature.
z Select Page Down to turn pages of the body marks. If there is only one page, selecting
this button will not change anything.
z Current BM (Body Mark) 1
st
The Current BM (Body Mark) has two statuses, “1
st
” and “2
nd
”. The Current BM 1
st
is
default.
a) To add two body marks on an image, after you add one body mark, you shall
move the cursor onto the Current BM 1
st
and press [Set] to show the Current
BM 2
nd
.
b) Click [Current BM] to switch between the current operating body mark.
15.4 Adding Body Marks
The following will describe the steps to add the first Body Mark graphic to the imaging window.
