Mitsubishi FX3U-16CCL-M User Manual

10 Buffer Memory
10.3 Parameter information area
100
FX3U-16CCL-M User's Manual
10.3.10 [BFM#32 to #47] Station information
Set the station type for connected remote stations, intelligent device stations and reserved stations.
*1. BFM#32 to #39: 0101H to 0108H, BFM#40 to #47: 0000H
1. The figure below shows the data configuration to be set
2. The table below shows the buffer memory address for each units.
For example, when setting for the 10th units, write the buffer memory address "BFM#41".
3. Setting example
The table below shows the system configuration and station information setting.
• System configuration
• Station information setting
BFM No.
Description R/W Default
Hex. Dec.
#20H to
#2FH
#32 to #47 As shown below R/W *1
Unit
BFM No.
Unit
BFM No.
Hex. Dec. Hex. Dec.
1st unit #20H #32 9th unit #28H #40
2nd unit #21H #33 10th unit #29H #41
3rd unit #22H #34 11th unit #2AH #42
4th unit #23H #35 12th unit #2BH #43
5th unit #24H #36 13th unit #2CH #44
6th unit #25H #37 14th unit #2DH #45
7th unit #26H #38 15th unit #2EH #46
8th unit #27H #39 16th unit #2FH #47
BFM No.
Station type
Number of occupied
stations
Station No. Setting value
Hex. Dec.
#20H #32 0H 1H 01H 0101H
#21H #33 5H 2H 02H 5202H
#22H #34 6H 4H 04H 6404H
Station type
Number of occupied
stations
Station No.
b15 b12to b11 b8to b7 b0to
1: Occupies 1 station
2: Occupies 2 stations
3: Occupies 3 stations
4: Occupies 4 stations
1 to 16
(01H to 10H)
0H: Ver. 1 compatible remote I/O station
1H: Ver. 1 compatible remote device station
2H: Ver. 1 compatible intelligent device station
5H: Ver. 2 compatible single remote device station
6H: Ver. 2 compatible single intelligent device station
8H: Ver. 2 compatible double remote device station
9H: Ver. 2 compatible double intelligent device station
BH: Ver. 2 compatible quadruple remote device station
CH: Ver. 2 compatible quadruple intelligent device station
EH: Ver. 2 compatible octuple remote device station
FH: Ver. 2 compatible octuple intelligent device station
Master
station
Station No. 1
(occupies 1
station)
Ver. 1 compatible
remote I/O station
Station No. 2
(occupies 2
stations)
Ver. 2 compatible single
remote device station
Station No. 4
(occupies 4
stations)
1st unit 2nd unit 3rd unit
Ver. 2 compatible single
intelligent device station
