Appendix C: Differences with FX2N-16CCL-M
This appendix describes the major differences between the FX3U-16CCL-M and the FX2N-16CCL-M.
Appendix C-1 Differences with FX2N-16CCL-M
The difference between FX3U-16CCL-M and FX2N-16CCL-M is shown in the following table.
FX3U-16CCL-M FX2N-16CCL-M
CC-Link applicable version Ver. 2.00 (Ver. 1.10 also supported.) Ver. 1.00
Connectable station classification
• Remote I/O station
• Remote device station
• Intelligent device station
• Remote I/O station
• Remote device station
Maximum number of connectable
stations
• Remote I/O station: 8 maximum
(FX3G PLC: 4 maximum)
• Remote device station + Intelligent device
station: 8 maximum
• Remote I/O station: 7 maximum
• Remote device station: 8 maximum
Unit reset function from sequence
program
Not provided Provided
Parameter registration to EEPROM Not provided Provided
Parameter verification test Not provided Provided
Expanded cyclic setting Provided Not provided
Slave station refresh/compulsory
clear setting in case of programmable
controller CPU STOP
Provided Not provided
Consistency control function Provided Not provided
Connectable PLC FX3G, FX3U, FX3UC PLC
FX1N, FX1NC, FX2N, FX2NC, FX3G, FX3U,
FX3UC PLC
Number of connectable units to the
main unit
Only one FX3U-16CCL-M unit can be
connected in a main unit.
(An FX3U-16CCL-M cannot be attached to
main unit with an FX2N-16CCL-M.)
The number of connectable units is based on
the main unit.
(The maximum units number which can be
connected.)
