8.2 Parameter Setting Items
8.2 Parameter Setting Items
The table below shows the items set in the buffer memory "parameter information area" in the master station.
*1. BFM#32 to #39: 0101H to 0108H, BFM#40 to #47: 0000H
BFM No.
Item Description
Initial
value
Reference
Hex. Dec.
#0H #0 Mode
Sets the operation mode of the master station.
[Setting range]
0: Remote net ver. 1 mode
1: Remote net additional mode
2: Remote net ver. 2 mode
K0
Subsection
10.3.1
#1H #1
Number of connected
units
Sets the number of remote station and intelligent device station
(including reserved stations) connected to the master station.
[Setting range]
For FX3U/FX3UC PLC
1 to 16 (units)
For FX3G PLC
1 to 12 (units)
K8
Subsection
10.3.2
#2H #2 Number of retries
Sets the number of retries executed when communication error
occurs.
[Setting range]
1 to 7 (times)
K3
Subsection
10.3.3
#3H #3
Number of automatic
return units
Sets the number of remote station and intelligent device station which
can recover in one link scan.
[Setting range]
1 to 10 (units)
K1
Subsection
10.3.4
#6H #6
Operation
specification when
CPU is down
Specifies the data link status when an error occurs in the master
station PLC CPU.
[Setting range]
0: Stop
1: Continue
K0
Subsection
10.3.5
#0CH #12
Data link disorder
station setting
Specifies the input status for the data link error station.
[Setting range]
0: Hold
1: Clear
K1
Subsection
10.3.6
#0DH #13
Case of CPU STOP
setting
Specifies the slave station refresh/compulsory clear setting at
programmable controller CPU STOP.
[Setting range]
0: Refresh
1: Clears compulsorily
K0
Subsection
10.3.7
#10H #16
Reserved station
specification
Specifies reserved stations.
[Setting range]
0 to FFFEH (Set to ON the bits corresponding to the station numbers
to be set as reserved.)
K0
Subsection
10.3.8
#14H #20
Error invalid station
specification
Specifies invalid stations.
[Setting range]
0 to FFFFH (Set to ON the bits corresponding to the station numbers
to be set as error invalid stations.)
K0
Subsection
10.3.9
#20H to
#2FH
#32 to
#47
Station information
Sets the type of connected remote station and intelligent device
station (including reserved stations).
[Setting range]
As shown below
*1
Subsection
10.3.10
Station type
Number of occupied
stations
Station No.
b15 b12to b11 b8to b7 b0to
1: Occupies 1 station
2: Occupies 2 stations
3: Occupies 3 stations
4: Occupies 4 stations
1 to 16
(01H to 10H)
0H: Ver. 1 compatible remote I/O station
1H: Ver. 1 compatible remote device station
2H: Ver. 1 compatible intelligent device station
5H: Ver. 2 compatible single remote device station
6H: Ver. 2 compatible single intelligent device station
8H: Ver. 2 compatible double remote device station
9H: Ver. 2 compatible double intelligent device station
Ver. 2 compatible quadruple remote device station
Ver. 2 compatible quadruple intelligent device station
Ver. 2 compatible octuple remote device station
BH:
CH:
EH:
Ver. 2 compatible octuple intelligent device station
FH:
