2.5.2 Maximum transmission distance (for Ver. 1.10)
The relation of the transmission speed and maximum overall cable distance when configuring the entire
system with Ver. 1.10 units and cable is shown below.
• Ver.1.10 compatible CC-Link dedicated cable (requiring terminal resistor of 110 )
2.6 CC-Link Dedicated Cable
Use dedicated CC-Link cables in the CC-Link system.
If any other cable is used, the performance of the CC-Link system cannot be guaranteed.
For the specifications of CC-Link dedicated cables, please refer to the CC-Link Partner Association or the
following website.
- CC-Link Partner Association:
http://www.cc-link.org/
Remarks
For details, refer to the CC-Link wiring manual is sued by CC-Link Partner Association.
Transmission speed Cable length between stations
Maximum transmission
distance
156 kbps
20 cm or more
1200 m
625 kbps 900 m
2.5 Mbps 400 m
5 Mbps 160 m
10 Mbps 100 m
Master station
Remote I/O station
or remote device
station
Remote I/O station
or remote device
station
Intelligent device
station
Intelligent device
station
Maximum transmission distance
Cable length between
stations
