R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
192User Manual 1335.7352.02 ─ 02
Existing files will be overwritten. You can change the storage location, file name and/or
file format manually in the menu. Remote control uses the recent settings.
Parameters:
<FileName> String parameter
Example:
FORM CSV
EXP:WAV:SOUR CH1
EXP:WAV:NAME “/USB_FRONT/CHANNEL1.CSV“
EXP:WAV:SAVE
The waveform data is saved to CHANNEL1.CSV.
EXPort:WAVeform:SAVE
Saves the waveform and starts the export to USB drive.
Usage:
Event
13.3.7 Logic Channel
LOGic<l>:POSition.........................................................................................................192
LOGic<l>:SIZE.............................................................................................................. 193
LOGic<l>:STATe............................................................................................................193
LOGic<l>:LABel............................................................................................................. 193
LOGic<l>:LABel:State.....................................................................................................193
POD:THReshold............................................................................................................ 193
POD:THReshold:UDLevel<u>......................................................................................... 194
POD:State.....................................................................................................................194
POD:DATA?..................................................................................................................194
POD:DATA:HEADer?..................................................................................................... 195
POD:DATA:POINts........................................................................................................ 195
POD:DATA:XINCrement?............................................................................................... 196
POD:DATA:XORigin?.....................................................................................................196
POD:DATA:YINCrement?............................................................................................... 196
POD:DATA:YORigin?.....................................................................................................196
POD:DATA:YRESolution?...............................................................................................196
POD:CURRent:STATe:MINimum?...................................................................................197
POD:CURRent:STATe:MAXimum?..................................................................................197
LOGic<l>:POSition <Position>
Set the position of a logic channel.
Suffix:
<l>
.
Selects the logic channel (0...7).
Parameters:
<Position> Position value in divisions.
Acquisition and Setup
