R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
232User Manual 1335.7352.02 ─ 02
CALCulate:QMATh:DATA:YORigin?
Returns the voltage value for binary value 0 of the indicated waveform. The command
is relevant for data conversion, if binary data format is defined (FORM UINT,8|16|32).
Return values:
<Yorigin> Voltage in V
Usage: Query only
CALCulate:QMATh:DATA:YRESolutiont?
Return the vertical bit resolution of the indicated waveform. The command is relevant
for data conversion, if binary data format is defined (FORM UINT,8|16|32).
Return values:
<Yresolution> For default waveforms, the resolution is 8 bit.
If high resolution, average or filter are set, the resolution is
16 bit.
Usage: Query only
13.7.2 Reference Waveforms
REFCurve<m>:STATe....................................................................................................232
REFCurve<m>:SOURce.................................................................................................233
REFCurve<m>:SOURce:CATalog?..................................................................................233
REFCurve<m>:UPDate.................................................................................................. 233
REFCurve<m>:SAVE..................................................................................................... 233
REFCurve<m>:LOAD.....................................................................................................234
REFCurve<m>:LOAD:STATe..........................................................................................234
REFCurve<m>:HORizontal:SCALe.................................................................................. 234
REFCurve<m>:HORizontal:POSition................................................................................235
REFCurve<m>:VERTical:SCALe..................................................................................... 235
REFCurve<m>:VERTical:POSition...................................................................................235
REFCurve<m>:DATA?................................................................................................... 235
REFCurve<m>:DATA:HEADer?.......................................................................................235
REFCurve<m>:DATA:XINCrement?.................................................................................236
REFCurve<m>:DATA:XORigin?...................................................................................... 236
REFCurve<m>:DATA:YINCrement?.................................................................................236
REFCurve<m>:DATA:YORigin?...................................................................................... 237
REFCurve<m>:DATA:YRESolution?................................................................................ 237
REFCurve<m>:STATe <State>
Displays or hides the selected reference waveform.
Suffix:
<m>
.
1..4
Selects the reference waveform, the internal reference storage.
Quickmath and Reference Waveforms
