R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
264User Manual 1335.7352.02 ─ 02
Usage: Query only
EXTern:DATA:YORigin? <Yorigin>
Returns the voltage value for binary value 0 of the indicated waveform. The command
is relevant for data conversion, if binary data format is defined (FORM UINT,8|16|32).
Parameters:
<Yorigin> Voltage in V
Usage: Query only
EXTern:DATA:YRESolution?
<Yresolution>
Returns the voltage value for binary value 0 of the indicated waveform. The command
is relevant for data conversion, if binary data format is defined (FORM UINT,8|16|32).
Parameters:
<Yresolution> For default waveforms, the resolution is 8 bit.
If high resolution, average or filter are set, the resolution is
16 bit.
Usage: Query only
13.16 Protocol Analysis
● General................................................................................................................. 264
● Parallel / Parallel Clocked Bus..............................................................................267
● SPI Bus................................................................................................................. 269
● SSPI Bus...............................................................................................................276
●
I
2
C Bus..................................................................................................................279
● UART.................................................................................................................... 290
● CAN.......................................................................................................................296
● LIN.........................................................................................................................308
13.16.1 General
BUS<b>:STATe............................................................................................................. 265
BUS<b>:TYPE...............................................................................................................265
BUS<b>:FORMat...........................................................................................................265
BUS<b>:DSIZe..............................................................................................................265
BUS<b>:DSIGnals......................................................................................................... 266
BUS<b>:POSition.......................................................................................................... 266
BUS<b>:LABel.............................................................................................................. 266
BUS<b>:LABel:STATe................................................................................................... 266
Protocol Analysis
