R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
303User Manual 1335.7352.02 ─ 02
BUS<b>:CAN:FRAMe<n>:STARt?
Returns the start time of the specified frame.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame (1...n).
Return values:
<StartTime> Range: depends on sample rate, and time base
Default unit: s
Usage: Query only
BUS<b>:CAN:FRAMe<n>:STOP?
Returns the end time of the specified frame.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame (1...n).
Return values:
<StopTime> Range: depends on sample rate, and time base
Default unit: s
Usage: Query only
BUS<b>:CAN:FRAMe<n>:TYPE?
Returns the type of the specified frame.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame (1...n).
Return values:
<FrameType> DATA | REMote | ERR | OVLD
DATA
Frame type is data.
REMote
Frame type is remote.
ERR
Frame type is error.
OVLD
Frame type is overload.
Usage: Query only
Protocol Analysis
