R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
217User Manual 1335.7352.02 ─ 02
CURSor<m>:FUNCtion <Type>
Defines the cursor measurement type.
Parameters:
<Type> HORizontal | VERTical | PAIRed | HRATio | VRATio | PPCount |
NPCount | RECount | FECount | MEAN | RMS | RTIMe | FTIMe |
PEAK | UPEakvalue | LPEakvalue
*RST: PAIR
HORizontal Sets two horizontal cursor lines and measures the voltages at the two cursor
positions and the delta of the two values.
VERTical Sets two vertical cursor lines and measures the time from the trigger point to
each cursor, the time between the two cursors and the frequency calculated
from that time.
PAIRed V-Marker
HRATio Ratio of the x-values (e.g. a duty cycle) between the first and second cursors
and the first and third cursors.
VRATio Ratio of the y-values (e.g. overshooting) between the first and second cursors
and the first and third cursors.
PPCount
NPCount
RECount
FECount
Count positive pulses
Count negative pulses
Count rising edges
Count falling edges
Sets two vertical and one horizontal cursor line. The time base is defined by
the vertical cursors, the horizontal cursor defines the threshold value.
MEAN
RMS
Mean value
Root mean square
Values are measured between two vertical cursor lines.
RTIMe
FTIMe
Rise time, t
r
Fall time, t
f
The reference level for rise and fall time measurement is set with
REFLevel<m>:RELative:MODE
PEAK
UPEakvalue
LPEakvalue
Vpp, absolute difference between the two peak values
V
p+
, upper peak value
V
p-
, lower peak value
Values are measured between two vertical cursor lines.
CURSor<m>:SOURce <Source>
Defines the cursor measurement source as one of the active signal, reference or math
channel.
