R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
327User Manual 1335.7352.02 ─ 02
Example:
MMEM:DATA "abc.txt", #216This is the file
#2: the length infomation has two digits
16: the binary data has 16 bytes.
MMEM:DATA? "abc.txt"
received: This is the file
MMEMory:STORe:STATe <StateNumber>,<FileName>
Saves the current device settings to the specified file in the current directory.
Setting parameters:
<StateNumber> State 0 (low) or 1 (high)1
<FileName> String parameter
Path and file name
Example:
MMEM:CDIR "/USB_FRONT/DATA"'
MMEM:STOR:STAT 1,"MORNING.SET"
Usage: Setting only
MMEMory:LOAD:STATe <StateNumber>,<FileName>
Loads the device settings from the specified file in the current directory.
Setting parameters:
<StateNumber> State 0 (low) or 1 (high)1
<FileName> String parameter
Path and file name
Example:
MMEM:CDIR "/USB_FRONT/DATA"'
MMEM:LOAD:STAT 1,"MORNING"
Usage: Setting only
13.18 General Instrument Setup
For printer settings, see Chapter 13.17.1, "Output Control", on page 318.
CALibration................................................................................................................... 328
CALibration:STATe?.......................................................................................................328
DISPlay:LANGuage........................................................................................................328
SYSTem:NAME............................................................................................................. 329
SYSTem:DATE..............................................................................................................329
SYSTem:TIME...............................................................................................................329
SYSTem:TREE?............................................................................................................329
SYSTem:SET................................................................................................................ 329
SYSTem:ERRor[:NEXT]?................................................................................................330
SYSTem:ERRor:ALL?.................................................................................................... 330
SYST:PRESet............................................................................................................... 330
