MASK:CHCopy
Creates a mask from the envelope waveform of the test source set with MASK:SOURce
.
Usage: Event
MASK:YPOSition <Yposition>
Moves the mask vertically within the display.
Parameters:
<Yposition> Mask offset from the vertical center
Range: -200 to 200
*RST: 0
Default unit: div
MASK:YSCale <Yscale>
Changes the vertical scaling to stretch or compress the mask in y-direction.
Parameters:
<Yscale> A value over 100 % stretches the amplitudes; a value less than
100 % compresses the amplitudes.
Range: 10 to 1000
*RST: 100
Default unit: %
MASK:YWIDth <Yaddition>
Changes the width of the mask in vertical direction.
Parameters:
<Yaddition> The value is added to the y-values of the upper mask limit and
subtracted from the y-values of the lower mask limit.
Range: 0 to 5.12
*RST: 0
Default unit: div
MASK:XWIDth <Xaddition>
Changes the width of the mask in horizontal direction.
Masks
