Remote Commands Reference

R&S

RTC1000

248User Manual 1335.7352.02 ─ 02

MASK:ACTion:WFMSave:DESTination <File>

Defines the path and filename for a waveform data that will be saved on mask viola-

tion. The file format is CSV, the filename is incremented automatically

You can change the storage location, file name and/or file format manually in the FILE

> "Waveforms" menu. Remote control uses the recent settings.

Parameters:

<File> String parameter

Example:

MASK:ACT:WFMS:DEST "/USB_FRONT/MASKS/VIOL"

On first violation, the waveform data is saved to VIOL.CSV, on

second violation to VIOL01.CSV, the third to VIOL02.CSV ...

MASK:RESet:COUNter

Sets the counters of passed and failed acquisitions to zero.

Usage:

Event

13.10 Function Generator

GENerator:FUNCtion......................................................................................................248

GENerator:VOLTage...................................................................................................... 248

GENerator:VOLTage:OFFSet..........................................................................................249

GENerator:FREQuency.................................................................................................. 249

GENerator:FUNCtion:RAMP:POLarity..............................................................................249

GENerator:FUNCtion:PULSe:DCYCle..............................................................................249

GENerator:OUTPut[:ENABle].......................................................................................... 249

GENerator:FUNCtion <Function>

Selects the generator function.

Parameters:

*RST: SIN

GENerator:VOLTage <Amplitude>

Defines the amplitude value (peak-peak value) of the selected generator function.

Parameters:

<Amplitude> Range: 6.0000E-02 to 6.00000E+00

*RST: 5.0000E-01

Default unit: Vpp
