Remote Commands Reference

R&S

RTC1000

195User Manual 1335.7352.02 ─ 02

POD:DATA:HEADer?

Returns information on the digital channel waveform.

Position Meaning Example

1 XStart in s -9.477E-008 = - 94,77 ns

2 XStop in s 9.477E-008 = 94,77 ns

3 Record length of the waveform in samples 200000

4 Number of values per sample interval, usually 1. 1

Return values:

<Header> Comma-separated value list.

Example:

-9.477E-008,9.477E-008,200000,1

Usage: Query only

POD:DATA:POINts

As a setting, the command selects a range of samples that will be returned with POD:

DATA?. As a query, the command returns the number of returned samples for the

selected range. If ACQuire:WRATe is set to MSAMples (maximum sample rate), the

memory usually contains more data samples than the screen can display. In this case,

you can decide which data will be saved: samples stored in the memory or only the

displayed samples.

Parameters:

<PointSelection> DEFault | MAXimum | DMAXimum

Sets the range for data queries.

DEFault

Waveform samples displayed on the screen.

MAXimum

Range is the complete memory

Note: Reading the complete memory is only possible in STOP

mode, and if maximum sample rate is set (ACQuire:WRATe

ACQ:WRAT MSAM)

DMAXimum (Display Maximum)

Number of samples in the current waveform record.

*RST:

DEFault

Return values:

<Points> Number of data points in the selected range.

Default unit: Samples
