R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
285User Manual 1335.7352.02 ─ 02
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Return values:
<Access> INComplete | READ | WRITE | EITHer | UNDF
INComplete
The frame is incomplete.
READ
read frame
WRITE
write frame
EITHer
Either write or read frame.
UNDF
The frame is undefined.
Usage:
Query only
BUS<b>:I2C:FRAMe<n>:AMODe?
Returns the address mode.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Return values:
<AddressMode> BIT7 | BIT10
BIT7
7 Bit address
BIT10
10 Bit address
Usage: Query only
BUS<b>:I2C:FRAMe<n>:AACCess?
Returns the address acknowledge bit value for the indicated frame.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Protocol Analysis
