287User Manual 1335.7352.02 ─ 02
Suffix:
<b>
.
1, 2
Selects the bus.
<n> *
Selects the frame.
Return values:
<StartTime> Range: depends on sample rate, and time base
Default unit: s
Usage: Query only
BUS<b>:I2C:FRAMe<n>:ADBStart?
Returns the start time of the address acknowledge bit.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Return values:
<AckStartTime> Range: depends on sample rate, and time base
Default unit: s
Usage: Query only
BUS<b>:I2C:FRAMe<n>:ACOMplete?
Returns the state of the address.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Return values:
<AddressComplete> ON | OFF
ON
Address was received completely.
OFF
Address was not received completely.
Usage: Query only
BUS<b>:I2C:FRAMe<n>:BCOunt?
Returns the number of data bytes of a frame.
Protocol Analysis
