R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
312User Manual 1335.7352.02 ─ 02
TRIGger:A:LIN:CHKSerror <ChecksumError>
Triggers on a checksum error when trigger type is set to error condition, using
TRIGger:A:LIN:TYPE. The checksum verifies the correct data transmission. It is the
last byte of the frame response.
Parameters:
<ChecksumError> ON | OFF
*RST: ON
TRIGger:A:LIN:IPERror <IdParityError>
Triggers on a parity error when trigger type is set to error condition, using TRIGger:
A:LIN:TYPE. Parity bits are the bits 6 and 7 of the identifier. They verify the correct
transmission of the identifier.
Parameters:
<IdParityError> ON | OFF
*RST: OFF
TRIGger:A:LIN:SYERror <SyncError>
Specifies the trigger on synchronisation error when trigger type is set to error, using
TRIGger:A:LIN:TYPE.
Parameters:
<SyncError> ON | OFF
*RST: OFF
13.16.8.3 Decode
BUS<b>:LIN:FCOunt?.................................................................................................... 313
BUS<b>:LIN:FRAMe<n>:BCOunt?.................................................................................. 313
BUS<b>:LIN:FRAMe<n>:STATus?.................................................................................. 313
BUS<b>:LIN:FRAMe<n>:STARt?.................................................................................... 314
BUS<b>:LIN:FRAMe<n>:STOP?..................................................................................... 314
BUS<b>:LIN:FRAMe<n>:VERSion?.................................................................................315
BUS<b>:LIN:FRAMe<n>:DATA?..................................................................................... 315
BUS<b>:LIN:FRAMe<n>:IDSTate?.................................................................................. 315
BUS<b>:LIN:FRAMe<n>:IDValue?.................................................................................. 316
BUS<b>:LIN:FRAMe<n>:IDPValue?................................................................................ 316
BUS<b>:LIN:FRAMe<n>:SYSTate?.................................................................................316
BUS<b>:LIN:FRAMe<n>:CSSTate?.................................................................................317
BUS<b>:LIN:FRAMe<n>:CSValue?................................................................................. 317
BUS<b>:LIN:FRAMe<n>:BYTE<o>:STATe?.....................................................................317
BUS<b>:LIN:FRAMe<n>:BYTE<o>:VALue?..................................................................... 318
Protocol Analysis
