R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
286User Manual 1335.7352.02 ─ 02
Return values:
<Acknowledge> INComplete | ACK | NACK | EITHer
INComplete
Acknowledge is incomplete
ACK
Acknowledge
NACK
No Acknowledge
EITHer
ACK or NACK
Usage: Query only
BUS<b>:I2C:FRAMe<n>:ADDRess?
Returns the decimal address value of the indicated frame including the R/W bit.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Return values:
<AddressValue> Decimal value
Range: 0 to 2047
Increment: 1
Usage: Query only
BUS<b>:I2C:FRAMe<n>:ADEVice?
Returns the decimal address value of the indicated frame without R/W bit.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Return values:
<SlaveAddress> Decimal value
Range: 0 to 1023
Increment: 1
Usage: Query only
BUS<b>:I2C:FRAMe<n>:ASTart?
Returns the start time of the address for the indicated frame.
Protocol Analysis
