Remote Commands Reference
R&S
®
RTC1000
202User Manual 1335.7352.02 ─ 02
Parameters:
<Slope> POSitive | NEGative | EITHer
POSitive
Rising edge, a positive voltage change
NEGative
Falling edge, a negative voltage change
EITHer
Rising as well as the falling edge
*RST: POSitive
TRIGger:A:EDGE:COUPling
<Coupling>
Sets the coupling for the trigger source.
Parameters:
<Coupling> DC | AC | HF | ALEVel
DC
Direct Current coupling. The trigger signal remains unchanged.
AC
Alternating Current coupling. A 5 Hz high pass filter removes the
DC offset voltage from the trigger signal.
HF
High frequency coupling. A 15 kHz high-pass filter removes
lower frequencies from the trigger signal. Use this mode only
with very high frequency signals.
ALEVel
Auto Level
*RST:
DC
TRIGger:A:EDGE:FILTer:LPASs <State>
Turns an additional 5 kHz low-pass filter in the trigger path on or off. This filter removes
higher frequencies and is available with AC and DC coupling.
Parameters:
<State> ON | OFF
*RST: OFF
TRIGger:A:EDGE:FILTer:NREJect <State>
Turns an additional 100 MHz low-pass filter in the trigger path on or off. This filter
removes higher frequencies and is available with AC and DC coupling.
Parameters:
<State> ON | OFF
*RST: OFF
Trigger
