RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 284

Dec 10, 2015

Table 4-20. Settings of Registers When Using Pins of Port 10 as Analog Inputs

Pin Name PM10x ADPC

Alternate Function

Setting

Remark

Name I/O

P10n Input 1 14 to n + 14H

(n = 0 to 4),

00H (n = 5)



To use P10n as an analog

input, use these pins from the

lower bit.

Remarks 1. PM10x: Port mode register 9

ADPC: A/D port configuration register

2. n = 0 to 5

Table 4-21. Setting Functions of P100/ANI18 to P105/ANI23 Pins

ADPC Register PM10 Register ADS Register P100/ANI18 to P105/ANI23 Pins

Digital I/O selection Input mode



Digital input

Output mode



Digital output

Analog input selection Input mode Selects ANI. Analog input (to be converted)

Does not select ANI. Analog input (not to be converted)

Output mode Selects ANI. Setting prohibited

Does not select ANI.

Reset signal generation sets P100/ANI18 to P105/ANI23 to analog input mode.
