Relay Clutch
1. Rear cover ( p.76)
2. Relay clutch [A] ( x 1)
Relay Sensor
1. Relay clutch ( p.117)
2. Sensor bracket [A] ( x 1)
3. Relay sensor [B] ( x 1)
Paper Feed Section
117
