Image Density Sensor
1. Open the right door.
2.
Plastic cover [A]
3.
Image transfer roller ( p.120)
4.
Push down on the notch [B] to free the sensor.
5.
Image density sensor [C] ( x 1)
Image Transfer
121
4
