• There is no standard value for the nip band on this machine. Make the adjustment based on the
band's appearance.
8. If
the band is not as described above, change the position of the spring hooks [C] (one on each side),
and then check the band again.
• The higher hook position produces greater tension.
Cleaning Roller
1. Pressure roller and bushings ( p.125)
2. Cleaning roller [A]
Fusing
127
4
