4.Replacement and Adjustment
102
Image Adjustment
Registration Adjustment
User Adjustment
The paper registration can also be adjusted with the user mode ("User Tools "). For details, see the
"User Guide".
Service Adjustment
1. Enter the "Maintenance Mode (SP mode)".
For information on how to enter the "Maintenance Mode (SP mode)", contact the supervisor in your
branch office.
2. Print test pattern pages. (To Print the Test Pattern)
3. Select [Registration].
4. Select the item you want to adjust.
5. Press the [ ] or [ ] keys (for touch panel models, press [+] or [-]) to set the registration value (mm).
Increase the value to shift the print area in the plus direction.
Decrease to shift in the minus direction.
Adjust the margins of the test page so that they are equal in size.
(1): Feed Direction
(2): Vertical Adjustment
(3): Horizontal Adjustment
(4): Print Area
