Ricoh FAX1120L Field Service Manual

6.Troubleshooting
187
Fax Error Codes
Fax Error Code Structure
This section describes the dial, transmission (TX), and reception (RX) error codes that are printed on
the TX Report/Activity Report.
Error codes consist of six hexadecimal digits (0-5).
Digit 5 (far left)
TX or RX
1xxxxx
TX (Fax)
2xxxxx
RX (Fax)
Digit 4
Coding (MH/MR/MMR/JBIG)
x1xxxx
MH
x2xxxx
MR
x3xxxx
MMR
x4xxxx
JBIG
Digit 3
Modem mode
xx1xxx
V27ter non-ECM
xx2xxx
V29 non-ECM
xx3xxx
V17 non-ECM
xx4xxx
V33 non-ECM
xx5xxx
V34
xx9xxx
V27ter ECM
xxaxxx
V29 ECM
xxbxxx
V17 ECM
xxcxxx
V33 ECM
Digit 2
Modem speed
xxx1xx
2400
xxx2xx
4800
xxx3xx
7200
xxx4xx
9600
xxx5xx
12000
xxx6xx
14400
xxx7xx
16800
xxx8xx
19200
xxx9xx
21600
xxxaxx
24000
