7.Detailed Descriptions
203
No.
Item
3.
Registration clutch
4.
Relay clutch
5.
Paper feed clutch
Component Layout (Printer Models)
Laser Exposure
No.
Description
1
Quenching lamp
2
Toner end sensor
3
ID chip board
4
LD driver board
5
Polygon mirror motor
6
Laser unit thermistor
