4.Replacement and
Ad
justment
84
3.
Remove the thermostat [A].
Fusing
Thermistor
1.
Remove the fusing unit (
Fusing Unit
).
2.
Remove the fusing upper cover (
Fusing Upper Cover
).
3.
Remove the fusing front cover [A].
4.
Remove the fusing thermistor [A].
Fusing Lamp
1.
Remove the fusing unit (
Fusing Unit
).
