7.Detailed Descriptions
211
ADF/ARDF (for MF models)
Overview
ADF
No.
Item
1.
Original set sensor
2.
Pick-up roller
3.
Separation roller
4.
Feed roller
5.
ADF feed sensor
6.
Exposure glass
7.
Exit roller
8.
Stopper
ARDF
No.
Item
1.
Original set sensor
