7.Detailed Descriptions
231
Mechanism
Fusing Drive
No.
Item
1.
Main motor
2.
Duplex motor
3.
Paper exit roller
4.
Hot roller
5.
Pressure roller
The main motor drives the fusing unit through a gear train.
