Ricoh FAX1120L Field Service Manual

5.System Maintenance
110
Menu
Description
[-2.0 to 2.0 / 0 (Default)/ 0.1mm/step]
Flatbed Sub Reg.
Adjusts the Flatbed Scan sub-scan registration.
[-2.0 to 2.0 / 0 (Default)/ 0.1mm/step]
Size Adjust
ADF Main Reg.
Adjusts the ADF Scan main-scan magnification.
[-0.9 to 0.9 / 0 (Default)/ 0.1 %/step]
ADF Sub Reg.
Adjusts the ADF Scan sub-scan magnification.
[-0.9 to 0.9 / 0 (Default)/ 0.1 %/step]
Flatbed Main Reg.
Adjusts the Flatbed Scan main-scan magnification.
[-0.9 to 0.9 / 0 (Default)/ 0.1 %/step]
Flatbed Sub Reg.
Adjusts the Flatbed Scan sub-scan magnification.
[-0.9 to 0.9 / 0 (Default)/ 0.1 %/step]
Factory Default
Menu
Description
Factory
Default
Return
Does not execute anything. Returns to an upper level.
Execute
Resets all the settings to factory default.
Clears/ resets the contents of the controller memory (all data programmed
by the user, log data application counters) to factory default.
After executing, initial setup menu starts after power-on.
CTL Maintenance
Menu
Description
PDL Mode
ON = "PDL Settings" is shown in [Print List/Report] menu (Default)
OFF = "PDL Settings" is hidden
FW Update
Mode
If updating firmware on a machine in which LDAP authentication is set, execute this
mode.
[Execute/ Return]
After pressing “Execute”, the display shows “Please Restart Machine….” Turn the
machine's main power off, and then on. Then the machine activates in a special boot
loader mode. After that, update the firmware via USB cable.
Auto IP
ON = Automatically set an IP address when an IP address cannot be acquired
(Default)
OFF = Continually try to obtain an IP address by DHCP
Disable
USB Port
Sets whether the USB port function is valid or invalid
[Off (Default)/On]
Paas
When used to set Paas (Only for CHN)
