IP-Fax Troubleshooting
SM 51 D649
Fax Option
Type C305
(D649)
7 Enable H.323 SW is set to on?
Request the sender to check the settings.
User Parameter SW 34 Bit 0/SW 34 bit 1
 Only if the remote sender fax is a
Ricoh fax.
8 Local fax IP address registered? Register the IP address.
9 Local fax Alias number registered? Register the Alias number.
10 Network bandwidth too narrow?
Request the system administrator to
increase the bandwidth.
Lower the start modem reception baud rate
on the receiving side.
IPFAX SW06
11 Remote fax cancelled transmission?
Check whether the remote fax cancelled
the transmission.
12
Local fax registered in Gatekeeper/SIP
server ?
Contact the network administrator.
 The sender machine displays this
error code when the sender fax is
a Ricoh model.
To Next Page
