SMC List Card Save Function
D117/D118 5-44 SM
5.13 SMC LIST CARD SAVE FUNCTION
5.13.1 OVERVIEW
SMC List Card Save
The SMC List Card Save (SP Text Mode) function is used to save the SMC list as CSV files to
the SD-card inserted into the operation panel SD-card slot.
5.13.2 PROCEDURE
1. Turn the main power switch OFF.
2. Insert the SD card into the operation panel SD-card slot. Then turn the power ON.
3. Enter SP mode.
4. Select “Copy SP”.
5. Select SP-5992 "SP Text Mode”.
6. Select a detail SP number shown below to save data on the SD card.
SP-5992-xxx (SP Text Mode)
Detail No. SMC Categories to Save
001 All (Data List)
002 SP (Mode Data List)
003 User Program
004 Logging Data
005 Diagnostic Report
006 Non-Default
007 NIB Summary
To Next Page
