Input Check Table
SM 5-7 D117/D118
System
Maintenance
5803 Description
Reading
0 1
5803-014 Right Cover Sensor Door close Door open
5803-015 +24V_DCTH Detection (Not used)
5803-016 ITB Contact HP Sensor Not contact Contact
5803-017 Paper Transfer Contact Sensor Not contact Contact
5803-018 ITB New Unit Detection (Not used)
5803-019 Toner Collection Full Sensor Not full Full
5803-020 Toner Collection Bottle Set Set Not set
5803-021 Toner Collection Motor Set: C (Not used)
5803-022 Toner End Sonsor: Y Not end End
5803-023 Toner End Sonsor: M Not end End
5803-024 Toner End Sonsor: C Not end End
5803-025 Toner End Sonsor: K (Not used)
5803-026 Fusing Entrance Sensor Paper detected Paper not detected
5803-027 Fusing Exit Sensor Paper detected Paper not detected
5803-028 Fusing Destination Detection - -
5803-029 Fusing New Unit Detection New Not new
5803-030 Fusing High Temp Detection Detected Not detected
5803-031 Zero-cross Signal Not detected Detected
5803-032 Fusing Air Flow Fan: Lock Lock Normal
5803-033 LD Unit Fan: Lock Lock Normal
5803-034 PSU Fan: Lock Lock Normal
5803-035 Drum Fan: Lock Lock Normal
5803-036 Reserve Fan: Lock Lock Normal
