Siemens siprotec 7SD5 User Manual

3.1 Mounting and Connections
459
7SD5 Manual
C53000-G1176-C169-1
Table 3-5 Jumper settings of the Control Voltages of the binary inputs BI1 to BI8 on the
input/output board C-I/O-1 with housing size
1
/
2
1)
Factory settings for devices with power supply voltages 24 VDC to 125 VDC
2)
Factory settings for devices with power supply voltages of 110 VDC to 250 VDC and 115 VAC
3)
Factory settings for devices with power supply voltages of 220 VDC to 250 VDC and 115 VAC
Table 3-6 Jumper settings of the Control Voltages of the binary inputs BI1 to BI24 on the
input/output board C-I/O-1 or C-I/O-10 with housing size
1
/
1
1)
Factory settings for devices with power supply voltages 24 VDC to 125 VDC
2)
Factory settings for devices with power supply voltages of 110 VDC to 250 VDC and 115 VAC
3)
Factory settings for devices with power supply voltages of 220 VDC to 250 VDC and 115 VAC
Table 3-7 Jumper settings of the Board Address of the input/output board C-I/O-1 or C-
I/O-10 with housing size
1
/
1
binary inputs
slot 19
Jumper 19 V Threshold
1)
88 V Threshold
2)
176 V Threshold
3)
BI1 X21/X22 L M H
BI2 X23/X24 L M H
BI3 X25/X26 L M H
BI4 X27/X28 L M H
BI5 X29/X30 L M H
BI6 X31/X32 L M H
BI7 X33/X34 L M H
BI8 X35/X36 L M H
Binary inputs Jumper 19 V
Threshold
1)
88 V
Threshold
2)
176 V
Threshold
3)
Slot 33 left
side
Slot 19
right side
Slot 19 left
side
BI1 BI9 BI17 X21/X22 L M H
BI2 BI10 BI18 X23/X24 L M H
BI3 BI11 BI19 X25/X26 L M H
BI4 BI12 BI20 X27/X28 L M H
BI5 BI13 BI21 X29/X30 L M H
BI6 BI14 BI22 X31/X32 L M H
BI7 BI15 BI23 X33/X34 L M H
BI8 BI16 BI24 X35/X36 L M H
Jumper Mounting location
Slot 19 left side Slot 19 right side
X71 H L
X72 L L
X73 H H
