Siemens TC35i Terminal User Manual

TC35i AT Command Set
8.7 AT^MONI
s
m obil e
TC35i_ATC_V02.07 Page 200 of 439 1/30/04
Confidential / Released
• The length of following output lines exceeds 80 characters. Therefore a terminal program may draw a carriage
return on a screen. However, this is not part of the response.
8.7.1 AT^MONI responses
ME is not connected:
a) ME is camping on a cell and registered to the network:
b) ME is camping on a cell but not registered to the network (only emergency call allowed):
c) ME camping on a cell, but searching for a better cell (cell reselection):
d) ME is searching and could not (yet) find a suitable cell:
ME is connected (Call in progress):
Columns for Serving Cell:
Serving Cell I Dedicated channel
chann rs dBm PLMN LAC cell NCC BCC PWR RXLev C1 I chann TS timAdv PWR dBm Q ChMod
1013 21 -71 00101 1001 0103 7 7 33 -105 33 I No connection
Serving Cell I Dedicated channel
chann rs dBm PLMN LAC cell NCC BCC PWR RXLev C1 I chann TS timAdv PWR dBm Q ChMod
1013 21 -71 00101 1001 0103 7 7 33 -105 33 I Limited Service
Serving Cell I Dedicated channel
chann rs dBm PLMN LAC cell NCC BCC PWR RXLev C1 I chann TS timAdv PWR dBm Q ChMod
1013 21 -71 00101 1001 0103 7 7 33 -105 33 I Cell Reselection
Serving Cell I Dedicated channel
chann rs dBm PLMN LAC cell NCC BCC PWR RXLev C1 I chann TS timAdv PWR dBm Q ChMod
Searching
Serving Cell I Dedicated channel
chann rs dBm PLMN LAC cell NCC BCC PWR RXLev C1 I chann TS timAdv PWR dBm Q ChMod
1013 19 -76 00101 1001 0103 7 7 33 -105 33 I 1015 1 0 5 -76 0 S_HR
Column Description
chann ARFCN (Absolute Frequency Channel Number) of the BCCH carrier
rs RSSI value 0 - 63 (RSSI = Received signal strength indication)
dBm receiving level of the BCCH carrier in dBm
PLMN PLMN ID code
LAC location area code, see note below
cell cell ID, see note below
NCC PLMN colour code
BCC base station colour code
