101
Transition Rate
You can set the time taken from the beginning of a
transition to its completion.
The transition rate is configured using the Flexi Pad
con
trol block, utility/shotbox control block and numeric
keypad control block, or the menu.
When a clip transition is selected as the transition type, it
is n
ot possible to set the transition rate.
Transition Rate Input/Display Mode
Transition rate input mode
When entering the transition rate, you can select either
f
rame number input or timecode input.
For details, see “Timecode input and frame number
input” (page 78).
Frame number input:
Enter a number in the range 0 to 999 frames.
Timecode input:
Enter a value converted to frames of up to 999 frames.
Transition rate display mode
You can set the transition rate display mode to frame
nu
mber display or timecode display.
The display mode settings are common to all switcher
ban
ks.
For details, see “Setting the transition rate display”
(page 417).
Frame number display:
Displays the number of frames (0 to 999). Values
e
ntered in timecode input mode are converted to the
number of frames for display.
Timecode display:
Displays a “ss:ff” timecode value (second:frame).
Va
lues entered in frame input mode are converted to
a timecode for display.
Setting the Transition Rate
You can set the speed at which a transition switches from
the current image to a new image (time taken from the
beginning of a transition to its completion).
In an auto transition, the transition is executed
a
utomatically with the preset transition rate.
Setting the transition rate (Flexi Pad
control block)
You can set the transition rate using the Flexi Pad control
block of the target switcher bank.
1
Press the [TRANS RATE] button.
The memory recall section switches to transition rate
ope
ration mode.
2
Enter a transition rate using the number input buttons.
You can switch the input mode using the [TC] button.
In frame number input mode, enter three digits. In
t
imecode input mode, enter four digits.
The entered value appears in the top right button of
t
he memory recall section.
To delete the entered value
Press the [CLEAR] button.
3
Press the [ENTER] button.
Setting the transition rate (utility/shotbox
control block and numeric keypad control
block)
When the utility/shotbox control block is switched to
transition rate display mode, the transition rate is
displayed in the memory recall section. Press a memory
recall button to select a transition rate, and set it using the
numeric keypad control block.
You can change the transition rate display mode
tr
ansition rate assignments.
For details, see “Setting Transition Rate Display Mode
Buttons” (page 405).
1
Press the [TRANS RATE1] button to [TRANS
RATE3] button in the utility/shotbox control block.
The memory recall section switches to transition rate
di
splay mode.
2
Press the memory recall button displaying the target
transition rate to set, turning it on.
The target region name and transition rate to set are
shown
on the display of the numeric keypad control
block.
3
Enter a transition rate using the numeric keypad of the
numeric keypad control block.
You can switch the input mode using the [TC] button.
Note
Note
