63
ICP-X7000 Control Panel
Bottom view
a DC IN connector
Connect to the supplied AC adaptor.
b L
AN connector (RJ-45, PoE+, 1000BASE-T
compliant)
Connect to the switcher system network via an Ethernet
swit
ch.
Operation without using the AC adaptor is supported
usi
ng a PoE+ (Power over Ethernet Plus) compatible
Ethernet switch.
For details about PoE+ (Power over Ethernet Plus)
compat
ible Ethernet switches that can be used, consult
your Sony representative.
a
b
ICP-X7000 Integrated Control Panel
MKS-X7075 Extension Adaptor
