Edge Effects
This section describes the menu for DME channel 1 as an
example.
Setting a Border
1
Open the Home > DME > Channel1 > Edge > Border/
Crop menu (15101.21).
2
Set the [Border] button to the on state and set the
following parameters.
a) The [Density] parameter in numbers 1-5 and 2-5 are common.
3
In the [Border Fill] group, select a signal to insert in
the border.
Flat Color: Si
ngle color
Ext Video: Ex
ternal input (Ext In) signal
When the [Flat Color] button is selected, set the
f
ollowing parameters.
To soften the border
Set the [Border Soft] button to the on state and set the
fo
llowing parameter.
Setting a Crop
1
Open the Home > DME > Channel1 > Edge > Border/
Crop menu (15101.21).
2
Set the [Crop] button to the on state and set the
following parameters.
a) The entered numeric value is automatically a positive value for the
right and top edges and a negative value for the left and bottom
edges.
To soften the edges
Set the [Edge Soft] button to the on state and set the
f
ollowing parameter.
Linking the crop areas when inverting
1
Open the Home > DME > Channel1 > Edge > Border/
Crop menu (15101.21).
2
In the [Invert/Crop Process] group, select the
operation when inverting.
Crop -> Invert:
With the axis of symmetry at the
center of the input image, invert both the central
image and the crop area horizontally and
vertically around the axis of symmetry. The order
of effect application for the input image is Crop
and then Invert.
Invert -> Crop:
With the axis of symmetry at the
center of the input image, invert only the central
image horizontally and vertically around the axis
of symmetry. The order of effect application is
Invert and then Crop.
No. Parameter Adjustment
1-1 H Simultaneous adjustment of
b
order width of left and right
edges
1-2 V Simultaneous adjustment of
b
order width of top and
bottom edges
1-3 All Simultaneous adjustment of
b
order width of top, bottom,
left, and right edges
1-5 Density Density of border
a)
2-1 Top Border width of top edge
2-2 Left Border width of left edge
2-3 Right Border width of right edge
2-4 Bottom Border width of bottom edge
2-5 Density Density of border
a)
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
No. Parameter Adjustment
1 Soft Softness of inner edge of border
No. Parameter Adjustment
1-1 H Simultaneous adjustment of
c
rop of left and right edges
a)
1-2 V
Simultaneous adjustment of
crop of top and bottom edges
a)
1-3 All Simultaneous adjustment of
crop of top, bottom, left, and
right edges
a)
2-1 Top Crop of top edge
2-2 Left Crop of left edge
2-3 Right Crop of right edge
2-4 Bottom Crop of bottom edge
No. Parameter Adjustment
1 Soft Edge softness
To Next Page
