List of Utility Commands
The following utility commands can be assigned.
Command Function
M/E-x PGM1 ST
a)
M/E-x PGM2 ST
a)
M/E-x PGM3 ST
a)
M/E-x PGM4 ST
a)
Enable/disable M/E-x program output safe title
x = 1 to 5
M/E-x PVW ST
a)
Enable/disable M/E-x preview output safe title
x = 1 to 5
M/E-x CLEAN ST
a)
Enable/disable M/E-x clean output safe title
x = 1 to 5
M/E-x K-PVW1 ST
a)
M/E-x K-PVW2 ST
a)
Enable/disable M/E-x key preview output safe title
x = 1 to 5
P/P PGM1 ST
a)
P/P PGM2 ST
a)
P/P PGM3 ST
a)
P/P PGM4 ST
a)
Enable/disable P/P program output safe title
P/P PVW ST
a)
Enable/disable P/P preview output safe title
P/P CLEAN ST
a)
Enable/disable P/P clean output safe title
P/P K-PVW1 ST
a)
P/P K-PVW2 ST
a)
Enable/disable P/P key preview output safe title
Color Bkgd2 ST
a)
Enable/disable color background 2 output safe title
DME Monitor Video ST
a)
Enable/disable DME monitor video output safe title
DME Monitor Key ST
a)
Enable/disable DME monitor key output safe title
Frame Memory1 to 16 ST
a)
Enable/disable frame memory output (1 to 16) safe title
Clip Player1 to 4 ST
a)
Enable/disable clip player output (1 to 4) safe title
Multi Viewer1 ST
a)
Multi Viewer2 ST
a)
Enable/disable multi viewer output (1, 2) safe title
Edit Preview ST
a)
Enable/disable edit preview output safe title
Preset ST
a)
Enable/disable preset output safe title
Aux 1 to 48 ST
a)
Enable/disable AUX output (1 to 48) safe title
GPI 1 to 50 Test Fire Output test trigger from GPI output port
Macro Attachment Enbl Enable/disable macro attachment
Macro AT with Rate Register the transition rate when registering an auto transition macro event
Macro AT with A/B Bus Register the background A bus/B bus cross-points when registering an auto transition macro
ev
ent
Macro TL with Region Register the target region when registering an effect timeline macro event
Pre Macro Set macro attachment in pre-macro mode
Post Macro Set macro attachment in post-macro mode
Macro Take Resume macro execution
(Enabled in step execution mode or during a pause event with a pause time of “0”)
Macro All Take Resume all paused macros in multi mode
(Enabled in multi mode during a pause event with a pause time of “0”)
Macro Auto Ins Enable/disable macro auto insert mode
Macro Cancel Stop macro execution
Macro All Cancel Stop all simultaneous executing macros in multi mode
DME Override Enable/disable DME override
DME Graphic Enable/disable DME graphics display
(Applied to graphics for channel selected in device control block)
FTB Enable/disable fade-to-black
