Setting NDCP (LSM)
You can configure the required setting using the ST 2110
routing function of LSM (Live System Manager).
When the protocol is set to NMOS, NDCP(LSM) cannot
be conf
igured.
1
Open the Home > Setup > 100G IP I/F > Controller >
NDCP(LSM) menu (19108.14).
2
Select the target LAN port to set.
To select and set multiple LAN ports, place a check
mar
k beside the target LAN ports to set. To select and
set all LAN ports, place a check mark in the Select All
checkbox.
3
Check the DHCP setting state.
Enable: Obt
ain LSM address automatically using
DHCP is enabled.
Disable: Ob
tain LSM address automatically using
DHCP is disabled.
Set to “Disable” (fixed).
4
Set the [LSM Enable] switch.
On:
Use the port for control communication with
LSM.
Off: Do no
t use the port for control communication
with LSM.
LAN port 1-1-1 is set to “On” (fixed), and “Enable”
is d
isplayed.
5
Press the [LSM IP Address] button and enter an
address using the keyboard.
Cannot be set when [LSM Enable] is turned off.
6
Press the [Apply] button.
To return to the previous setting
Press the [Clear] button.
7
Check the message, then press [OK].
To check the LSM (Live System Manager) connection
statu
s
You can check the LSM connection information for each
100G p
ort using [Connection Status] in the Home > Setup
> 100G IP I/F > Controller > NDCP(LSM) menu
(19108.14).
Connected: Conn
ected
Disconnected: Disc
onnected
At least one 100G port on each box must be
con
nected.
