388
2
Select the [Logical Box ID] tab, switch boxes, and
select the target physical M/E block/sub block to set.
3
Set the [SL Key] switch to the on state.
To disable an SL key, set the [SL Key] switch to the
o
ff state.
Setting the Operation Mode and
Output for a Switcher Bank
Setting the operation mode
You can select from the following four operation modes
for each switcher bank.
Standard mode
Four outputs are assigned as follows (fixed).
Out1: Program 1 output
Out2: Preview 1 output
Out3: Clean output
Out4: Key preview 1 output
Multi program mode
Up to eight outputs can be used.
Out1: Program 1 output (fixed) is assigned.
Out2 to Out8: You can assign the following outputs.
Program 1 to 4 outputs
Preview 1 output
Clean output
Key preview 1 and 2 outputs
When M/E split is enabled, Out5 to Out8 cannot be used.
Multi program 2 mode
Up to eight outputs can be used.
Out1: Program 1 output (fixed) is assigned.
Out2 to Out8: You can assign the following outputs.
Program 1 to 4 outputs
Preview 1 and 2 outputs
Clean output
Sub clean output
Key preview 1 and 2 outputs
DSK mode
Six outputs are assigned as follows (fixed).
Out1: Program 1 output
Out2: Program 2 output
Out3: Program 3 output
Out4: Program 4 output
Out5: Key preview 1 output
Out6: Key preview 2 output
When M/E split is enabled, four outputs are assigned as
fo
llows (fixed).
Out1: Program 1 output
Out2: Program 2 output
Out3: Key preview 1 output
Out4: Key preview 2 output
• When M/E split is enabled, multi program 2 mode
cann
ot be selected.
• DSK mode can be selected only when the switcher bank
i
s assigned to P/P.
1
Open the Home > Setup > Switcher > Config > M/E
Config menu (19103.12).
2
Select the target switcher bank to set.
3
Press the [M/E Config] button and select an operation
mode from the pull-down list.
Standard: St
andard mode
Multi Program: M
ulti program mode
Multi Program 2: Mu
lti program 2 mode
DSK: DS
K mode
Setting the output configuration
You can set the output signal configuration of a switcher
bank when in multi program mode or multi program 2
mode.
• The output configuration for standard mode and DSK
mode
cannot be changed.
• Out1 is set to PGM1 (fixed).
• When M/E split is enabled, Out5 to Out8 cannot be
used.
1
Open the Home > Setup > Switcher > Config > M/E
Config menu (19103.12).
2
Select the target switcher bank to set.
3
Press the [Edit] button for [Output].
The [Output] window appears.
4
Press the button for the target output number (1 to 8)
and select an output signal from the pull-down list.
5
Press [OK].
Setting the program output
You can select the background and the keys to enable for
the program output.
1
Open the Home > Setup > Switcher > Config > PGM
Config menu (19103.13).
2
Select the target program output to set.
Notes
Notes
