131
Setting a border
1
Press the [BDR] button, turning it on green.
2
Set the following parameters.
The parameters will vary depending on the separate
ed
ge settings.
For details about separate edges, see “Setting
separate edges” (page 129).
When separate edges are disabled
When separate edges are enabled
To adjust the color of the edge fill signal
When a color matte is selected for the signal to insert in
an
edge, you can adjust color 1.
For details about selecting an edge fill signal, see
“Setting the edge type” (page 128).
Press the [MORE] button to display the page 2 parameters
and
set color 1.
Setting a drop border or shadow
1
Press the [DROP BDR] button or [SHDW] button,
turning it on green.
2
Set the following parameters.
To adjust the color of the edge fill signal
When a color matte is selected for the signal to insert in
an ed
ge, you can adjust color 1.
For details about selecting an edge fill signal, see
“Setting the edge type” (page 128).
Press the [MORE] button to display the page 2 parameters
and se
t color 1.
Setting soft edges
When chroma key shadow is enabled, soft edge is
disabled.
1
Press the [SOFT EDGE] button, turning it on green.
2
Set the following parameter.
Setting Key Drop
This section describes the M/E-1 key 1 menu as an
example.
Setting key drop on mode
You can set key drop on mode and select whether to move
the key fill/key source position downward by eight lines
or four lines.
In the following situations, key drop on mode is
aut
omatically enabled.
• When the edge type is border, outline, or emboss
• When fine key is enabled
• When soft edge is enabled
1
Open the Home > M/E-1 > Key1 > Edge > Edge Type
Select menu (11101.21).
2
Set the [Key Drop] button in the [Key Delay Mode]
group to the on state.
No. Parameter Adjustment
1 WIDTH Width
4 DENSITY Density
No. Parameter Adjustment
1 TOP Top edge width
2 LEFT Left edge width
3 RIGHT Right edge width
4 BOTTOM Bottom edge width
No. Parameter Adjustment
2-1 LUM Luminance
2-2 SAT Saturation
2-3 HUE Hue
2-4 DENSITY Density
No. Parameter Adjustment
1 WIDTH Width
2 POSITION Position
4 DENSITY Density
No. Parameter Adjustment
2-1 LUM Luminance
2-2 SAT Saturation
2-3 HUE Hue
2-4 DENSITY Density
Note
No. Parameter Adjustment
1 SOFT Edge softness
Note
